Chauvet DJ D-FI Hub Compact Wireless 2.4 GHz DMX Transmitter Receiver - 113116

Description

Chauvet DJ D-FI Hub Compact Wireless 2.4 GHz DMX Transmitter Receiver – 113116

The Chauvet D Fi Hub is a compact, easy to use DMX unit that functions as either a transmitter or receiver. For more stable communication between units, it operates on a 2.4 GHz frequency range and includes an “auto” function which automatically finds the best frequency and syncs the units effortlessly.With the Chauvet D Fi Hub you can wirelessly synchronize an unlimited number of D Fi™ ready fixtures simultaneously, and operate them using the simple navigation on the OLED digital display.

Features

Compact, easy to use wireless D Fi™ transmitter and receiver in a single unit
Wirelessly synchronize an unlimited number of D Fi™ ready fixtures and receivers simultaneously
Built in options include manual or automatic channel selection
Simple navigation and text readout using the OLED digital display
Mounting options include built-in hook and loop fastener strap, keyhole mounting holes, M10 and M12 threaded holes for direct mounting to truss
Fully FCC/RTTE compliant
Specifications:
DMX Connectors: 3 pin XLR
Operating Frequency: 2.412 to 2.484 GHz
Antenna connection: RP SMA
Max Unobstructed Distance: 656 feet
Input Voltage: 9 VDC, 500 mA (external power supply: 100 to 240 VAC, 50/60 Hz)
Power and Current: 4 W, 0.1 A 120 V, 60 Hz
Power and Current: 4 W, 0.1 A 230 V, 50 Hz
Approvals: CE, FCC
Dimensions: 4 x 3.2 x 1.6 inches
Weight: 1.2 pounds
Quantity: 2

What our Expect Think

Wireless DMX – Operates on a 2.4 GHz frequency, eliminating the need for physical DMX cables.
Compact & Portable – Small, lightweight design makes it easy to transport and set up for events.
Multiple DMX Channels – Supports up to 512 DMX channels for full control over your lighting systems.
Easy Pairing – Quick setup with automatic pairing between transmitter and receiver for smooth operation.
Reliable Performance – Provides a strong and stable signal for reliable wireless communication in crowded environments.

Q&A

Q: What is the CHAUVET DJ D-FI Hub?
A: The D-FI Hub is a compact wireless DMX transmitter and receiver that allows for wireless control of lighting fixtures over a 2.4 GHz wireless connection, eliminating the need for DMX cables.

Q: How does the D-FI Hub work?
A: It uses wireless DMX technology to transmit and receive control signals, enabling you to control your lights remotely, without the hassle of wires.

Q: What type of lighting equipment is compatible with the D-FI Hub?
A: The D-FI Hub is compatible with any DMX-controlled lighting fixture, including LEDs, moving heads, and effects lights.

Q: Is it easy to set up?
A: Yes, the D-FI Hub is plug-and-play, making setup simple and fast, especially for mobile DJs and event planners.

Maintenance Tips

Check Battery Levels – Ensure batteries are fully charged or fresh to maintain strong wireless connection.
Inspect Connections – Verify that all DMX cables are properly connected and secure.
Keep Antennas Clear – Avoid blocking antennas to ensure optimal signal transmission.
Store in a Dry Place – Keep the device in a cool, dry location to prevent damage from moisture.
Regularly Update Firmware – Ensure the device is running the latest firmware for enhanced performance.
