Briggs & Stratton 130G52-0182-F1 Horizontal Engine with 6:1 Gear Reduction

Description

Briggs & Stratton 130G52-0182-F1 Horizontal Engine with 6:1 Gear Reduction – BS,130G52-0182-F1

Briggs & Stratton 130G52-0182-F1 Horizontal XR950 Professional Series Engine with 6:1 Gear Reduction, 3/4″ x 2-27/64″ Crankshaft, 3/16″ Keyway, 5/16″-24 Drilled & Tapped, 208cc, Recoil Start, Replaces Model 12S452-0049-F8

Specifications

Brand	Briggs & Stratton
Model Number	130G52-0182-F1
Internal ID	BS-130G52-0182-F1
Warranty	2 Year Consumer / 1 Year Commercial
Weight	50.0 lb
PTO Height	4-11/64″
Max RPM	3600
Crankshaft Orientation	Horizontal
Crankshaft Type	Straight, Gear Reduction
Crankshaft Diameter	3/4″
Crankshaft Length	2-27/64″
Crankshaft Dimensions	3/4″ x 2-27/64″
End Tapped Size	5/16″-24
Keyway	3/16″
Rotation Direction	Counterclockwise
Ignition System	Electronic
Carburetor	Float
Number of Cylinders	One
Cylinder Bore	Cast Iron Sleeve
Air Cleaner	Dual Element
Oil Cooler	No
Oil Capacity	20 oz
Low Oil Alert	No
Low Oil Shutdown	No
Fuel Type	Gasoline
Fuel Tank Capacity	3.2 qt
Fuel Pump	No
Controls	Manual
Bolt Circle	3-5/8″
Charging System	None
Flywheel	Heavy
Applications	Aerators, Sprayer Pumps

What Our Experts Think

The Briggs & Stratton 130G52-0182-F1 Horizontal Engine with 6:1 Gear Reduction is a reliable and powerful choice for demanding applications. Here’s why it stands out:

Durable & Dependable: Built by Briggs & Stratton, a trusted name in small engines, ensuring long-lasting performance.
208cc Engine: Provides solid power for various equipment, from industrial machinery to agricultural use.
6:1 Gear Reduction: Enhances torque output, making it ideal for heavy-duty applications requiring controlled speed and high power.
Horizontal Shaft Design: Versatile for use in equipment such as cement mixers, pressure washers, and more.
Low Maintenance: Designed with efficiency and longevity in mind, requiring minimal upkeep for reliable performance.
Easy Start System: Ensures smooth and quick startups, even in tough conditions.
Compact & Versatile: Fits a wide range of applications while offering excellent power-to-size efficiency.

Q&A

Q: What is the Briggs & Stratton 130G52-0182-F1 Horizontal Engine?
A: The Briggs & Stratton 130G52-0182-F1 is a durable and reliable horizontal engine with a 6:1 gear reduction, designed for various industrial and commercial applications requiring reduced output speed and increased torque.

Q: What are its key features?
A: It features a 208cc displacement, a 6:1 gear reduction system for enhanced torque, a horizontal shaft for versatile mounting, a recoil start for easy operation, and a cast-iron sleeve for durability.

Q: What applications is this engine best suited for?
A: It is ideal for equipment requiring lower RPM and higher torque, such as cement mixers, power trowels, and other heavy-duty machinery.

Q: Is it fuel-efficient?
A: Yes, the engine is designed for efficiency, providing reliable power while maintaining fuel economy.

Q: Why choose the Briggs & Stratton 130G52-0182-F1 Engine?
A: With its robust construction, reliable performance, and 6:1 gear reduction for increased torque, this engine is an excellent choice for demanding applications requiring dependable power output.

Maintenance Tips

Check and Change Oil: Use SAE 30 or 10W-30 oil, and change it after the first 5 hours of use, then every 50 hours or as recommended. Always check the oil level before use.
Clean or Replace Air Filter: Inspect the air filter regularly and clean or replace it every 25 hours of use to maintain optimal performance.
Inspect and Replace Spark Plug: Check the spark plug every 100 hours or annually. Replace if worn or dirty to ensure easy starting and smooth operation.
Fuel Maintenance: Use fresh, clean fuel with a stabilizer. Avoid old or contaminated fuel, and drain the system if storing for an extended period.
Check Gear Reduction Lubrication: Ensure the 6:1 gear reduction unit is properly lubricated according to the manufacturer’s guidelines to prevent wear.
Clean Cooling System: Keep the engine cooling fins and intake areas free of debris to prevent overheating.
Inspect and Tighten Components: Regularly check bolts, nuts, and engine mounts to ensure everything is secure and vibration-free.
Store Properly: If not in use for a long period, drain the fuel, clean the engine, and store it in a dry, cool place to prevent corrosion.
