Aardwolf Rock Lifter Grapple - ARL-1200

Aardwolf Rock Lifter Grapple - ARL-1200

Rock Lifter Grapple also available in

Designed for the landscape contractor, stonemason, or anyone else who works regularly with rocks and boulders. The Rock Lifter Grapple is an efficient solution to work faster, better, and with less labor.

Features

• High tensile steel welded construction.
• Simple and reliable operation with minimal maintenance.
• A safer and easy way to move large rocks.
• Suitable for handling boulders and stones of almost all shapes.
• The greater the weight the harder the grip of the tongs.
• An actuator allows the clamp to grab and release automatically during each cycle.

Specifications

What our Experts Think

• Heavy-Duty Capacity:
  Designed to lift boulders up to 3,307 lbs (1,500 kg), with a grip range of 23.6" to 47.2" (600–1,200 mm), accommodating various rock sizes.

• Self-Adjusting Grip:
  Features a self-tightening mechanism that increases grip strength as the weight of the rock increases, ensuring secure handling.

• Automatic Operation:
  Equipped with an actuator for automatic gripping and releasing, streamlining the lifting process.

• Durable Construction:
  Built from high-tensile welded steel, offering resilience and longevity for demanding tasks.

• Minimal Maintenance:
  Engineered for simple operation with minimal upkeep, reducing downtime and maintenance costs.

• Versatile Applications:
  Ideal for landscaping, stonemasonry, and other industries requiring efficient handling of large rocks and boulders.

Q&A

Q: What is the Aardwolf Rock Lifter Grapple ARL-1200?
A: The ARL-1200 is a heavy-duty, self-adjusting grapple designed to safely lift and transport large rocks and boulders in landscaping, hardscaping, and construction projects.

Q: What is the lifting capacity of the ARL-1200?
A: It has a working load limit of 1,500 kg (3,307 lbs), making it suitable for handling substantial boulders.

Q: What is the grip range of the ARL-1200?
A: The grapple accommodates rocks with widths ranging from 600 mm to 1,200 mm (23.6" to 47.2").

Q: How does the ARL-1200 operate?
A: The grapple features an automatic actuator that grips and releases rocks with each cycle, adjusting its hold based on the weight of the material.

Q: What materials can the ARL-1200 handle?
A: It is designed to handle boulders and stones of various shapes and sizes, providing a secure grip for efficient transport.

Q: What are the dimensions and weight of the ARL-1200?
A: The unit weighs approximately 354 kg (780 lbs), with packaging dimensions of 1,850 mm x 950 mm x 1,500 mm (L x W x H).

Q: Where can I purchase the ARL-1200?
A: The ARL-1200 is available for purchase through various distributors and online retailers. Please check with local suppliers or online marketplaces for availability.

Maintenance Tips

1. Regular Cleaning:

• After each use, clean the grapple to remove dust, debris, and any material residues.

• Use a soft brush or cloth to clean the surfaces.

• Wipe all parts dry to prevent moisture buildup.

2. Structural Inspections:

• Periodically inspect the grapple for signs of wear or damage.

• Check for rust, bent components, or any structural issues.

• Address any issues promptly to maintain safety and functionality.

3. Lubrication:

• Lubricate moving parts, such as the actuator and pivot points, to ensure smooth operation.

• Use a suitable lubricant that does not attract excessive dust or debris.

4. Grip Mechanism Check:

• Test the automatic grip and release mechanism to ensure it functions correctly.

• If the mechanism is not engaging or releasing properly, clean and lubricate the components.

• Replace any worn or damaged parts promptly.
