QuickJack 7000TL | Portable Car Lift 7000 lb capacity - 5175640

QuickJack 7000TL | Portable Car Lift 7000 lb capacity - 5175640

QuickJack 7000TL is the only portable truck lift capable of getting trucks and SUV tires completely off the ground. With the addition of the optional Light Truck & SUV Adapters, the 7000TL has an incredible 27" lifting height. 7000TL is the highly-anticipated sequel to the most popular automotive tool to ever hit the home garage or auto repair shop. With the ability to lift an extra 3-inches, 7000TL portable car lift provides more room to tackle every repair and maintenance task on vehicles, trucks, and SUVs weighing up to 7,000-lbs.

Through superior engineering and design, we've been able to produce an extra 3-inches of lifting height without sacrificing the overall dimensions that has made QuickJack a must-have in your garage. 7000TL still has an impressive 3.5" lowered height, 70.75" overall length, and 12.5" overall width.

The BL-7000SLX is a 7,000-lb. capacity portable car lift that’s designed, engineered and manufactured by the same people who make traditional heavy-duty car lifts and truck lifts for professional shops and garages around the world. But like its “smaller” siblings (the BL-3500SLX and BL-5000SLX), the BL-7000SLX was born to be taken anywhere. No bolts. No wiring. Just two frames, a power source and a whole lot of mean. Throw it in a large trunk, backseat or truck bed when you need lifting power to go. Store the space-saving frame almost anywhere when it’s not in use.

What's the difference between the NEW TL Models vs. SLX Models?
The biggest difference between the 7000TL and BL-7000SLX is the lifting height, which has increased 3 inches. This provides ample room to perform all the common vehicle maintenance tasks and allows you the capability to perform even the most complicated repairs.

Overall dimensions have remained the same, so you'll continue to benefit from what made QuickJack so popular in the automotive community and that is it's super-low 3.5" lowered height. The minimum lifting point spread did change from 31.5" to 37", but this will not make a difference to the vast majority of 7000TL users.

Automatic safety locks
QuickJack 7000TL features automatic safety locks on each TL frame that engage at two positions. As the frames rise, these locks glide securely into place at mid-rise and full-rise. Disengage with a simple flip of the lock bar and your truck lift is ready for a smooth descent.

Increased lifting height
All QuickJack TL models are capable of lifting an extra 3-inches making it easier to perform vehicle maintenance tasks that are both routine and more involved. The extra room gives you more ability and versatility under the vehicle, while doing so in added comfort.

One-handed Operation
Simple one-handed controls are really as easy as a push of a button to lift and lower your QuickJack 7000TL. No cranking or bending during lifting.

Lifting capacity
7,000 lbs. (2,268 kg)

Lowered height
A - Frame only: 3.5" (89 mm)
B - With 2" block: 4" (102 mm)

Lifting height
D - With 2" block: 21.5" (546 mm)
E - With 3" block: 22.5" (572 mm)
F - Max. height: 24.5" (622 mm)
G - With adapters: 24.25" (610 mm)
H - With adapters + pin: 27" (686 mm)

Lift point spread
I - Maximum: 60" (1,524 mm)
J - Minimum: 37" (940 mm)

Frame dimensions (ea.)
K - Width: 12.5" (318 mm)
L - Length: 70.75" (1,797 mm)
A - Height (lowered): 3.5" (89 mm)
- Weight: 98 lbs. (45 kg)

Other specs
- Time to full rise: 30 seconds
- Power unit weight: 15 lbs. (7 kg)

• 7000TL Left Frame Assembly

• 7000TL Right Frame Assembly

• 1x Hydraulic power unit with control

• 4x Medium rubber lift blocks (2")

• 4x Tall rubber lift blocks (3")

• 2x Short hydraulic hoses

• 2x Long hydraulic hoses

• 2x Frame-positioning handles

• Fittings and thread tape for setup

• Instruction manual

• 3 liters of Automatic Transmission Fluid

• Air source to inflate air cylinders up to 50 PSI

• Assembly tools
