Aardwolf

Aardwolf Slab Lifter 50 with Rollers - AL50R

Aardwolf Slab Lifter 50 with Rollers - AL50R

1 Review

Only left!


Free Delivary


Limited Stocks

In Stock - Ready to be Shipped

Regular price $0.00 Sale price $945.00
Shipping calculated at checkout.

Quintity

View full details
SALE ENDS IN
07 HRS
23 MINS
28 SECS
DON'T MISS IT!

Popular Add on

$100.00

$30.00

$200.00

$70.00

Add-Ons Bundle

$100.00

$30.00

$200.00

$70.00

Bundle Offer

$300.00

$100.00

Recently Viewed

Aardwolf Slab Lifter 50 with Rollers - AL50R

Aardwolf Slab Lifter AL50 incorporates a spring-loaded latch that automatically releases the lifter from the slab once the slab has been fully lowered to the ground.

General

The patented Aardwolf Slab Lifter is an accessory for lifting and moving slab-form loads. The Aardwolf Slab Lifter incorporates a spring-loaded latch that automatically releases the lifter from the slab once the slab has been fully lowered to the ground. This makes the process of lifting and lowering of slabs a one-man operation.
Features
  • Size: Being of a compact construction, the Aardwolf Slab Lifter 50 allows for close packed stone slabs to be lifted out of racks and containers. Lower height slabs placed along side of taller slabs offer no problem, as is the case with scissor clamps.
  • Versatile: Ideal for construction work. Because the clamping mechanism is to the front of the slab, they allow panels to be placed close against walls.
  • Safety: Requires only a small movement of the slab to engage and grip the slab, which is generally well below the over balance angle thus eliminating the danger to the operator.
  • Secure: The Aardwolf clamps grip marble and granite slabs firmly. The Aardwolf Slab Lifter 50 has a force-multiplying factor of approximately 2.5 to 1.
Specifications
Grip Mechanism Automatically and securely grips
Padding Rubber-padded clamping supports and base
Wheel Size 2 Rubber Wheels – 10¼" x 2¼"
Loading Capacity 880 lbs
Product Weight 34 lbs
Support Plate Length 20"
Wheelbase 16"
Clamp Width 0 – 2¼"
Package Dimensions (L×W×H) 19.7" x 18.5" x 16.9"
Net Weight 30 lbs
Gross Weight 34 lbs
What our Experts Think
  • Compact Design: Ideal for lifting closely packed stone slabs from racks and containers, even when lower height slabs are placed alongside taller ones.

  • Versatile Application: Perfect for construction work, as the clamping mechanism is positioned at the front of the slab, allowing panels to be placed close against walls.

  • Safety: Requires only a small movement of the slab to engage and grip, minimizing the risk of overbalance and ensuring operator safety.

  • Secure Grip: The Aardwolf clamps firmly grip marble and granite slabs, with a force-multiplying factor of approximately 2.5 to 1.

Q&A

Q: What is the Aardwolf AL50R Slab Lifter used for?
A: The AL50R is designed for lifting and transporting stone slabs, such as granite and marble, in workshops and on job sites.

Q: What is its weight capacity?
A: It has a working load limit of 1,200 kg (2,646 lbs), suitable for heavy-duty lifting tasks.

Q: What is the grip range?
A: The lifter accommodates slabs with a thickness ranging from 10 mm to 50 mm (0.4" to 2").

Q: Is it easy to operate?
A: Yes, the clamping mechanism is positioned at the front of the slab, allowing panels to be placed close against walls, and requiring only a small movement to engage and grip the slab.

Q: What materials can it handle?
A: The AL50R is suitable for both rough and smooth stone surfaces, providing versatility in handling various types of slabs.

Q: What is its weight?
A: The net weight is approximately 19 kg (42 lbs), and the gross weight is 20 kg (44 lbs), making it manageable for operators.

Maintenance Tips
  • Inspect Regularly: Check the rollers, lifting arms, and locking mechanism for wear, damage, or misalignment.

  • Clean After Use: Remove dust, debris, and moisture from the rollers and lifting components to prevent buildup and ensure smooth operation.

  • Lubricate Moving Parts: Apply light oil or lubricant to the rollers and pivot points to reduce friction and maintain smooth movement.

  • Check Functionality: Verify that the locking and lifting functions are working properly and securely before use.

  • Proper Storage: Store the lifter in a dry, sheltered location to prevent rust and environmental damage.
